Hobby Components Ltd MAX7219 8 Digit Seven Segment Display Module

4.2 out of 5 stars 13 customer reviews

Price: £4.99 & FREE UK Delivery on orders dispatched by Amazon over £20. Delivery Details
Note: This item is eligible for click and collect. Details
Pick up your parcel at a time and place that suits you.
  • Choose from over 13,000 locations across the UK
  • Prime members get unlimited deliveries at no additional cost
How to order to an Amazon Pickup Location?
  1. Find your preferred location and add it to your address book
  2. Dispatch to this address when you check out
Learn more
    This fits your .
  • Make sure this fits by entering your model number.
  • This 8 digit seven segment display module (HCMODU0082) is based upon the Maxim MAX7219 LED display driver. The module uses two standard 4 digit seven segment displays to display a total of 8 digits in RED with decimal point. A convenient input and output header allows additional modules to be daisy-chained and controlled with just just 3 digital IO pins. To panel mounting the module has 4 mounting holes and 4 brass pillars with screws are supplied.
  • The Maxim MAX7219 driver allows for each segment of up to 8 digits (with decimal point) to be controlled individually from a serial interface. An 8x8 static ram area stores each digit and multiplexing the display is handled automatically.
  • If you plan to use this module with an Arduino board we have written an exclusive library (HCMAX7219) than allows you to effortlessly display and scroll alphanumeric characters across one or more modules. This can be downloaded from the software section of our support forum.
  • Example sketch, datasheet and exclusive library available from our support forum.
  • check out our blog posts "Getting Started with Seven Segment Serial Displays" and "Library for MX7219 LED Driver".
See more product details

Only on Amazon: One product for every need Only on Amazon: New Releases


Frequently bought together

  • Hobby Components Ltd MAX7219 8 Digit Seven Segment Display Module
  • +
  • Elegoo 120pcs Multicolored Dupont Wire 40pin Male to Female, 40pin Male to Male, 40pin Female to Female Breadboard Jumper Wires Ribbon Cables Kit for arduino
  • +
  • Elegoo UNO R3 Board ATmega328P ATMEGA16U2 with USB Cable for Arduino
Total price: £19.93
Buy the selected items together

What do customers buy after viewing this item?



Compare with similar items


Hobby Components Ltd MAX7219 8 Digit Seven Segment Display Module
kwmobile MAX7219 Dot Matrix Module - LED Matrix Display Module Control DIY Kit for Arduino and Raspberry Pi 4 in 1 8x8
Elegoo UNO Project Basic Starter Kit with Tutorial and UNO R3 for Arduino
HALJIA 5V MAX7219 8-Digit Red LED Display Control Module 7 Segment Digital Tube For Arduino MCU
kwmobile MAX7219 Dot Matrix Module - Red LED Matrix Display Module Control DIY Kit for Arduino and Raspberry Pi 8x8
MakerHawk 2pcs TM1638 Digital LED Display Module 8-Bit LED 8-Bit Digital Tube 8 KeyS with Dupont Cable for AVR Arduino
Add to Basket Add to Basket Add to Basket Add to Basket Add to Basket Add to Basket
Customer Rating 4 out of 5 stars (13) 3 out of 5 stars (5) 5 out of 5 stars (59) 0 out of 5 stars (0) 4 out of 5 stars (6) 4 out of 5 stars (16)
Price £4.99 £11.90 £14.69 £6.99 £5.90 £6.99
Shipping FREE UK Delivery on orders dispatched by Amazon over £20 FREE UK Delivery on orders dispatched by Amazon over £20 FREE UK Delivery on orders dispatched by Amazon over £20 FREE UK Delivery on orders dispatched by Amazon over £20 FREE UK Delivery on orders dispatched by Amazon over £20
Sold By Hobby Components Ltd KW-Commerce ElegooUK Hengjiaan KW-Commerce MakerHawk
Colour Multi-coloured White Red As Shown
Item Dimensions 19.61 x 10.61 x 1.89 cm 14.48 x 8.99 x 3.99 cm 6.03 x 4 x 1.33 cm 3 x 3 x 1 cm

Have a question?

Find answers in product info, Q&As, reviews

Please make sure that you've entered a valid question. You can edit your question or post anyway.

Don't see what you're looking for?
There was a problem completing your request. Please try your search again later.
All Product Information Customer Q&As Customer Reviews

Product information

Technical Details
Brand nameHobby Components Ltd
Item Weight9.07 g
Package Dimensions8.8 x 3 x 0.6 cm
Item model numberHCMODU0082

Additional Information
ASINB00W7MCZ7U
Customer Reviews 4.2 out of 5 stars 13 customer reviews
Best Sellers Rank 46,712 in Computers & Accessories (See top 100)
Shipping Weight9.1 g
Date First Available16 April 2015

Feedback
Would you like to tell us about a lower price?
If you are a seller for this product, would you like to suggest updates through seller support?


Product description

This 8 digit seven segment display module (HCMODU0082) is based upon the Maxim MAX7219 LED display driver. The module uses two standard 4 digit seven segment displays to display a total of 8 digits in RED with decimal point. A convenient input and output header allows additional modules to be daisy-chained and controlled with just just 3 digital IO pins. To panel mounting the module has 4 mounting holes and 4 brass pillars with screws are supplied.

The Maxim MAX7219 driver allows for each segment of up to 8 digits (with decimal point) to be controlled individually from a serial interface. An 8x8 static ram area stores each digit and multiplexing the display is handled automatically.

If you plan to use this module with an Arduino board we have written an exclusive library (HCMAX7219) than allows you to effortlessly display and scroll alphanumeric characters across one or more modules. This can be downloaded from the software section of our support forum.

Cable is not supplied. If you require a cable, please see our range of dupont cables.

Model number: HCMODU0082
Driver: Maxim MAX7921
Voltage: 4.0 - 5.5V
Max current: 180mA (all LEDs on)
Min current: <0.5mA (shutdown mode)
Length: 70mm
Width: 15mm
Height: 18mm (approx)

Example sketch, datasheet and exclusive library available from our support forum.

Also, check out our blog posts "Getting Started with Seven Segment Serial Displays" and "Library for MX7219 LED Driver".
